78-Series Master Cylinders

$235

SKU: Select 78-Series Master Cylinder option below Category: Tag:
Clear

Click here to find a Tilton dealer near you

78-Series master cylinders offer the latest in racing master cylinder technology in a very lightweight and compact design. The rear spherical bearing mount and one-piece piston/pushrod eliminate side thrust into the master cylinder bore, providing consistent and repeatable braking.

78-Series Master Cylinder Features

  • 40% lower price than 77‐Series master cylinders they replace ($235 vs $395 Retail)
  • Directly interchangeable with 77‐Series master cylinders
  • Billet aluminum body with proprietary low‐friction coatings minimize wear and provides smooth operation
  • Rear spherical bearing mount and one‐piece piston/pushrod eliminates side thrust into the master cylinder bore, providing consistent and repeatable braking
  • Hand‐built and blueprinted for cut‐off port travel
  • External dust boot included
  • O‐ring seal at the main rod guide and body interface
  • 1.1” of stroke
  • AN3 outlet port and AN6 inlet port
  • 7 bore sizes available
78-Series master cylinders are primarily designed for use with Tilton 800-Series and 900-Series pedal assemblies, but they can also be incorporated into custom pedal assembly designs.

Specs:

Bore Size

, , , , , ,
